Reed Switch / Auto Switch - SMT Series - SMT Series
Type Codes
|
Type Code |
Details |
|---|---|
|
001 Series |
SMT Proximity sensor |
|
002 Design type |
8 For T-slot |
|
003 Sensor version |
M Inserted in the slot from above |
|
004 Design |
A Short |
|
005 Switching output |
NO 3-wire N/C contact / NPN NS 3-wire NPN N/O contact / PO 3-wire PNP N/C contact / PS 3-wire PNP N/O contact / ZS 2-wire N/O contact |
|
006 Rated operating voltage |
24V DC, 110V AC, 220V AC (optional) |
|
007 Cable characteristic |
E Suitable for energy chains/robots |
|
008 Cable length [m] |
0.1 ... 30 m / 0,3 0.3 m / 2,5 2.5 m / 5,0 5 m / 7,5 7.5 m |
|
009 Cable identification |
With label holder / N Without label holder |
|
010 Connection technology |
OE Open end / M8 M8, snap-on flange / M8D M8, rotatable thread / M12 M12, rotatable thread |
